WSDEC1001 Conductivity Sensor

The WSDEC1001 is a digital online conductivity sensor that uses the four-electrode measuring principle for continuous monitoring of water conductivity. An AC voltage applied between the two outer electrodes induces an ionic current in the solution, proportional to the concentration of ions in the water; the current measured between the two inner electrodes gives the conductivity value. A built-in temperature sensor provides real-time temperature compensation, and the sensor converts the reading to a digital signal on board. Output is RS485 with the standard Modbus RTU protocol, which resists interference and carries the signal up to 500 m, and electrode parameters can be set and calibrated remotely.

Features

• Four-electrode conductivity measurement
• Range 0 … 2000 µS/cm, resolution 1 µS/cm
• Built-in temperature sensor with real-time compensation
• On-board digital signal conversion
• RS485 output with Modbus RTU, transmission up to 500 m
• Remote setting of electrode parameters and remote calibration
• Fast response, low maintenance cost and stable long-term operation
• Immersion or pipeline installation

How it works

• AC voltage is applied between the two outer electrodes
• This induces an ionic current proportional to the ion concentration
• The current between the two inner electrodes is measured to give conductivity

Applications

• Continuous online conductivity monitoring of water
• Immersion (sinking) installation
• Pipeline installation

LKS supplies the WSDEC1001 conductivity sensor in Malaysia, with installation, calibration and after-sales support. Contact our engineers for selection and a quotation.
