CCTV BNC Surge Protector LP-C/BNC

The LP-C/BNC is a DIN rail surge protector that guards CCTV and video monitoring systems against overvoltage caused by lightning strikes. It sits in the coaxial video line through BNC connectors and diverts surge current to earth before it reaches cameras or recorders. Multi-stage protection, combining a gas discharge tube to ground with a series resistor and a fast diode stage as shown in the wiring diagram, limits the residual voltage to below 80 V line to line. The unit mounts on a standard 35 mm rail and has a built-in 4 mm grounding terminal for a reliable earth connection, while its low insertion loss keeps the video signal clear.

Features

• Multi-protection technology for strong protection and high reliability
• Nominal discharge current 5 kA (8/20 µs), line to line and line to ground
• Voltage protection level < 80 V line-line, < 750 V line-GND/PE
• Transmission rate 16 MHz with insertion loss ≤ 0.5 dB
• BNC connections for coaxial video lines
• Built-in 4 mm grounding terminal for reliable earthing
• Mounts on 35 mm standard DIN rail
• Flame-retardant reinforced nylon housing (UL 94V-0)
• Compact and easy to fit

How it works

• Surge current on the video line is diverted to earth through a gas discharge tube
• A series resistor and diode stage clamp the remaining overvoltage on the output side

Applications

• CCTV systems
• Video monitoring systems

LKS supplies the LP-C/BNC surge protector in Malaysia, with installation and after-sales support. Contact our engineers for selection and a quotation.
